Description

ATEX IBC Container heaters is a special heater type designed and approved to Ex Zone 2 compliance with 94/9/EC (ATEX).

The container heaters are perfect to safely heat and keep fluids frost free in an IBC container.

The IBC heaters are designed in a durable and long lasting high quality lightweight design and the construction together with quick release webbing straps makes the drum heater easy to attach to any standard size of IBC tank.

Technical Description

• Nominal voltage: 115 or 230VAC, 50-60Hz
• Heating element: Self-limiting
• Power Connection: H07BQ-F, PUR coated, orange, acc VDE 0282 part 10 / HD 22.10
• Temperature Sensor: PT100/Thermocouple (optional): EEx-e or EEX-i
• Surface resistance: <3*10 Ω/m²
• Ambient Temperature: -15°C…+35°C
• Protection grade: IP65
• Directives and Norms: Atex directive 94/9/EG
• DIN EN 60079-0, DIN EN 60079-7
• DIN EN 60079-30
• DIN EN 13463-1
• Marking:ATEX ll 3G Ex e ll T5

Details

• Gentle and uniform heat transfer due to a dynamic and level depended heat emission
• Extended protection grade IP54 and hydrophobic materials
• Complete PTFE- (Teflon®) coating for a maximum long-life cycle and highest reliability against bases, acids, solvents, etc. – free of silicone.
• Circumferential (360°) belts with adjustable buckles ensuring an optimal fitting and easy handling
• Real 3-dimensional design for an optimal fitting and heat transfer

Specifications

TIP

For a faster and optimal heating process we recommend using the drum insulated lid (sold separately). The lid easily attaches to the top of the drum, reducing waste of heat.
