Air Diaphragm Pump Hygiene 397.5 l/min
Air diaphragm pump with a special design to make it suitable for CIP and SIP cleaning. Ideal to be used in all applications were hygienic pumping is required.
Flow rate : 397,5 l/min.
Pressure max: 8 bar.
Description
Air Diaphragm Pump Hygiene 397.5 l/min
The VA-2H40 SB/3A is a hygienic designed electrical or air operated double diaphragm pump. With the wide range of materials for valve seats, ball valves and diaphragms, this pump is the ideal problem solver for numerous hygienic applications. The VA-2H series is used where a high degree of food safety is required. The VA-2H is a reliable, easy to operate pump.
If 3A certification requested, the Verderair HI-CLEAN 3A version can be used. This pump is having more a leak detector.
The pumps are standard supplied mounted on a base frame on which the pump can be turned to drain the remaining of the media out of the pump.
Your benefits
- Most hygienic design for food applications
- Efficient engineered design which reduces the risk of contamination (low amount of products which come into contact with the medium)
- A high quality product with best price-performance ratio
- Can run against closed discharge valve without the need of overpressure safety equipment
- Dry self-priming
Technical Data
VA-2H40 SB | VA-2H40 3A | |
Max. flow | 397.5 l/min | 397.5 l/min |
Max. discharge pressure | 8 bar | 8 bar |
Max. particle size | 12.7 mm | 12.7 mm |
Viscosity | 15.000 cP | 15.000 cP |
Certificates | ATEX. EC 1935/2004. FDA. USP Class VI. CE. EN 2.1. EN 3.1 | ATEX. EC 1935/2004. FDA. 3A. USP Class VI. CE. EN2.1. EN3.1 |
Connections | Tri clamp and DIN | Tri clamp and DIN |
Air conn. | 1/2″ BSP/NPT | 1/2″ BSP/NPT |
Fluid surface finish | 0.8µm | 0.8µm |
Max. Suction lift (dry) | 3.0 m wc | 3.0 m wc |
Max. Suction lift (wet) | 9.1 m wc | 9.1 m wc |
Techinical Data Sheet | Download Datasheet | Download Datasheet |
