Έξυπνο Διπλό Όργανο για pH και Redox με Ethernet

pH and Redox Dual Smart Controller with Ethernet

Availability: in stock

SKU: DUAL PRO

pH and Redox Dual Smart Controller with Ethernet All in one. Double system with pH and Redox and temperature T ° instrument. Easy and direct setup. Double measuring instrument for pH and Redox with 2 peristaltic pumps. Choose the version with a Ethernet and WiFi connection from everywhere.

Buy together and win !

Redox Installation Kit for Swimming Pools

1 × Redox Installation Kit for Swimming Pools

pH Installation Kit for Swimming Pools

1 × pH Installation Kit for Swimming Pools

Product Type

Clear

Add to Wishlist

Compare

Description

pH and Redox Dual Smart Controller with Ethernet

pH and Redox Dual Smart Controller with Ethernet All in one. Double system with pH and Redox and temperature T ° instrument. Easy and direct setup. Double measuring instrument for pH and Redox with 2 peristaltic pumps. Adjustable in the entire range of PH and Redox ORP (mV).

Choose the version with a Ethernet and WiFi connection from everywhere
Choose the version with a socket outlet to connect a salt electrolysis unit (Reg) or an independent dosing pump

DUAL PRO PH/REDOX

Model	Max. l/h	Max cc/min	Pressure (bar)	Tube ø mm	Power cons. (Watt)	rpm	Pool (Volume)
pH pump	1.5	25	1	5.8 x 9.3	20	10	1 – 50 m³
Redox pump	3.0	50	1	5.8 x 9.3	20	20	40 – 120 m³
Redox pump	6.0	100	1	5.8 x 9.3	20	40	100 – 350 m³

Basic Cheracteristics

Double system with built in PH/REDOX
Backlit LCD display (DUAL PRO)
New 3.5″ high-contrast screen (TFT) (DUAL SMART)
Ethernet and WiFi connection for control from everywhere (DUAL SMART)
50 micron washable filter with probe holder with probes and buffer solutions
Overdose alarm built-in (TAL System)
Start-up delay & Password protected
pH stability mode for a perfect water disinfection
Flow rate display in %
3 operating modes: constant, ON / OFF, proportional
Four languages menu: English, French, Spanish and Italian
Default parameter restore option
STAND-BY function
Over/under range signal
Protection IP 65
Power Supply 230vac 50-60 Hz
Full chemical compatibility.

Versions

	Version DUAL PRO	Version WEB DUAL SMART
Flow sensor input for dosing according to water flow	✔	✔
Level probe sensor input for checking product levels	✔	✔
Alarm relay ( free contact)	✔	✔
Connect locally with WiFi with free app Android, Ios	✘	✔

Pack Contents

“DUAL PRO” or “DUAL SMART” control device.
2 x PVC Cristal 4×6 suction hose (4 m).
2 x Polyethylene delivery hose (5 m).
Attachment screw.
2 x Foot filter (PVC riser).
2 x FPM duckbill valve (3/8” GAS).

Accessories Not Included

11.100.178 PH Kit Installation	11.100.179 Redox Kit Installation	00.043.035 Single pH electrode	00.043.036 Single Redox electrode	AC.FT 1 Probe Holder

1 x pH electrode 1 x PSS probe-socket 1 x Tapping saddle DN50 2 x Buffer solution kit	1 x Redox electrode 1 x PSS probe-socket 1 x Tapping saddle DN50 1 x Buffer solution kit	pH electrode	Redox electrode	Probe holder “Bath type” for one sensor.
