Έξυπνο Διπλό Όργανο για pH και Redox με Ethernet

Smart Controller for pH and Chlorine with Ethernet

Availability: in stock

SKU: DUAL SMART PCL

Price range: 624,00 € through 1.044,00 €

Smart Controller for pH and Chlorine with Ethernet All in one. Double system with pH and Free Chlorine in ppm. Easy and direct setup. Choose the version with a Ethernet and WiFi connection from everywhere.

Product Type

Clear

Compare

Description

Smart Controller for pH and Chlorine with Ethernet

Smart Controller for pH and Chlorine with Ethernet All in one. Double system with pH and Free Chlorine in ppm and temperature T ° instrument. Easy and direct setup. Double measuring instrument for pH and Free Chlorine with 2 peristaltic pumps. Adjustable in the entire range of PH and Chlorine (ppm).

Choose the version with a Ethernet and WiFi connection from everywhere
Choose the version with a socket outlet to connect a salt electrolysis unit (Reg) or an independent dosing pump

DUAL PRO PH/REDOX

Model	Max. l/h	Max cc/min	Pressure (bar)	Tube ø mm	Power cons. (Watt)	rpm	Pool (Volume)
pH pump	1.5	25	1	5.8 x 9.3	20	10	1 – 50 m³
Redox pump	3.0	50	1	5.8 x 9.3	20	20	40 – 120 m³
Redox pump	6.0	100	1	5.8 x 9.3	20	40	100 – 350 m³

Basic Cheracteristics

Double system with built in PH/Chlorine Amperometric
Backlit LCD display (DUAL PRO)
New 3.5″ high-contrast screen (TFT) (DUAL SMART)
Ethernet and WiFi connection for control from everywhere (DUAL SMART)
50 micron washable filter with probe holder with probes and buffer solutions
Overdose alarm built-in (TAL System)
Start-up delay & Password protected
pH stability mode for a perfect water disinfection
Flow rate display in %
3 operating modes: constant, ON / OFF, proportional
Four languages menu: English, French, Spanish and Italian
Default parameter restore option
STAND-BY function
Over/under range signal
Protection IP 65
Power Supply 230vac 50-60 Hz
Full chemical compatibility.

Versions

	Version DUAL PRO	Version WEB DUAL SMART
Flow sensor input for dosing according to water flow	✔	✔
Level probe sensor input for checking product levels	✔	✔
Alarm relay ( free contact)	✔	✔
Connect locally with WiFi with free app Android, Ios	✘	✔

Pack Contents

“DUAL PRO” or “DUAL SMART” control device.
2 x PVC Cristal 4×6 suction hose (4 m).
2 x Polyethylene delivery hose (5 m).
Attachment screw.
2 x Foot filter (PVC riser).
2 x FPM duckbill valve (3/8” GAS).

Accessories Not Included

PRO-HCG-CL3 Amperometric Free Cl Reading Probe	11.100.178 PH Kit Installation	11.100.285 Suction Lance

Probe holder in plexiglass that allows the use of a pH or redox electrode and a temperature one.	1 x Redox electrode 1 x PSS probe-socket 1 x Tapping saddle DN50 1 x Buffer solution kit	Pre-assembled suction lance with foot filter and level probe for can 30 lt or plastic tank 100 lt.
