Dual Chlorinator and pH Controller with WiFi

Availability: in stock

SKU: DUAL BASIC

Dual Chlorinator and pH Controller with WiFi for swimming pools and water treatment plants. Easy and immediate set-up. Two buttons to program the system. Choose the version with a local WiFi connection or with a socket outlet to connect a salt electrolysis unit (Reg).

Buy together and win !

Redox Installation Kit for Swimming Pools

1 × Redox Installation Kit for Swimming Pools

pH Installation Kit for Swimming Pools

1 × pH Installation Kit for Swimming Pools

Product Type

Clear

Add to Wishlist

Compare

Description

Dual Chlorinator and pH Controller with WiFi

Dual Chlorinator and pH Controller with WiFi for swimming pools and water treatment plants. Easy and immediate set-up. Two buttons to program the system. Set point range between 6.0 and 8.0 PH interval
300 e 800 mV ORP interval. 4 in 1 (2instrument+2pump)

Choose the version with a local WiFi connection or with a socket outlet to connect a salt electrolysis unit (Reg) or an independent dosing pump.

DUAL BASIC PH/REDOX

Model	Max. l/h	Max cc/min	Pressure (bar)	Tube ø mm	Power cons. (Watt)	rpm	Pool (Volume)
pH pump	1.5	25	1	5.8 x 9.3	20	10	1 – 50 m³
Redox pump	3.0	50	1	5.8 x 9.3	20	20	40 – 120 m³
Redox pump	6.0	100	1	5.8 x 9.3	20	40	100 – 350 m³

Basic Cheracteristics

Double system with built in PH/REDOX
Flow rate showed in percentage
3 different functioning mode: constant, ON/OFF, proportional
Start-up delay & Password protected
pH stability mode for a perfect water disinfection
Four languages menu: English, French, Spanish and Italian
Default parameter restore option
STAND-BY function
Over/under range signal
Box in PP reinforced
Protection IP 65
Power Supply 230vac 50-60 Hz
ON/OFF switch
Full chemical compatibility.

Versions

	Version DUAL BASIC	Version DUAL BASIC+
Flow sensor input for dosing according to water flow	✘	✘
Level probe sensor input for checking product levels	✘	✘
Alarm relay ( free contact)	✘	✘
Connect locally with WiFi with free app Android, Ios	✘	✔

Pack Contents

“DUAL BASIC PH/RX” control device.
2 x PVC Cristal 4×6 suction hose (4 m).
2 x Polyethylene delivery hose (5 m).
Attachment screw.
2 x Foot filter (PVC riser).
2 x FPM duckbill valve (3/8” GAS).

Accessories Not Included

11.100.178 PH Kit Installation	11.100.179 Redox Kit Installation	00.043.035 Single pH electrode	00.043.036 Single Redox electrode	AC.FT 1 Probe Holder

1 x pH electrode 1 x PSS probe-socket 1 x Tapping saddle DN50 2 x Buffer solution kit	1 x Redox electrode 1 x PSS probe-socket 1 x Tapping saddle DN50 1 x Buffer solution kit	pH electrode	Redox electrode	Probe holder “Bath type” for one sensor.
